Planks

Planks
Planks
Product Code : IS 14862
Brand Name : Vplank
Product Description

Vplank is manufacturedas per ISO 8336/ IS 14862/ASTM C 1186 standards. They are available in standard dimensions with textured finishes to meet the requirements of modern external building applications.

A beautiful home is an essential requirement and desire of any individual.  Vplank can be craftfully used to decorate the home as per the taste and choice of the owner as it has innovative and multiple applications. The high aesthetic appeal of decorated  Vplank can replace other products like ACP, Wood siding etc.

Vplank advantage

  • Asbestos free
  • Energy efficient
  • Termite resistant
  • Weather resistant
  • Low shrinkage
  • Easy workability
  • Low operational cost
  • Sound insulation
  • Aesthetics with durability

S. No.

Properties

Units

Specification

References/Standards

50mm

75mm

A

Physical Properties









I

Nominal Weight Per Sq. Mtr

Kg/M2

Weight Physical

34

46

II

Axial Load











Samples Size 2.5 Meter 0.6 Meters

KN/M

ASTM E 72

54

Safety Factor 2.0

90

Safety Factor 2.0



Samples Size 1.5 Meter 0.3 Meters

KN/M

ASTM E  72

65

Safety Factor 2.0

100

Safety Factor 2.0

III

Multi Point Load











2.9 Meter Span

Kg/M2

ASTM E 72

125

150



2.4 Meter Span

Kg/M2

ASTM E 72

200

250



1.5 Meter Span

Kg/M2

ASTM E 72

450

500

IV

Uniform Distributed Load (Bag Test)

KNm/m

ASTM E 72

2.5

3.75

V

Tensile Strength Parallel to Surface

N/MM2

IS 2380 1977

1

0.9

VI

* Core Bonding Strength

N/MM2

IS 2380 1977

0.3

0.35

VII

Modulus of Rupture

Kg/cm2

IS 2380 1977

42

31

B

Thermal Properties









I

Thermal Resistance

M2K/W

IS:3346 1980

0.3

0.55

II

Overall Thermal Transmittance

W/ M2K

IS:3346 1980

1.8

1.5126

C

Acoustic Properties









I

Sound Transmission Class



dB

IS:9901 (Part II)-1981

Din:52210 (Part IV)-1984

ISO:140 (Part III)-1995

33

36

D

Fire Related Properties









I

Fire Rating

Minutes

       B5 476:Part 20&22

60

120

II

Surface Spread Flame

Class

BS 476 : Part 7

Class - I

Class – I

III

Fire Propagation Index

Index

BS 476 : Part 6

3.4

3.3

IV

Ignitability

Performance

BS 476 : Part 5

Class – P

Class - P

V

Combustibility

Performance

BS 476 : Part 4

Not Combustible

Not Combustible

E

Resistance to Air & Water



  BS 4315.2 1970

No dampness,

No leakage,

Increase in

weight - 4.5% (max)

No dampness,

No leakage,

Increase in

weight - 4.5% (max)

* No Debonding at the Interface between facing sheet and core material

Vpanel of standard width of 0.6 meters are available in lengths of 2.4, 2.7, 3.0 & 3.3 meters and in thicknesses of 50mm & 75mm
